Thermoelectric actuator Engo E30NC-230 for underfloor heating

Name: Thermoelectric actuator Engo E30NC-230 for underfloor heating
Brand: MC Therm
SKU: 85-030-671
Price: 9.98 EUR
Availability: InStock
Rating: 5.0 (6 reviews)

The ENGO E30NC-230is a reliable thermoelectric actuatorfor underfloor heating that precisely controlsthe flow of heating water in your underfloor heating sys...

★★★★★

5.0 6 Bewertungen | 〜 3 Personen sehen dieses Produkt gerade an

€9,98

Inkl. 19% MwSt. · Paketversand frei ab 100 €· INSTALLMENT PAYMENT POSSIBLE

Thread size: M30x1.5mm

Bis zu 10 % sparen, wenn du ein Komplettset kaufst Jetzt im Konfigurator zusammenstellen

→

Auf Lager

Only 12 sets available

Delivery by

✓NC (Normally Closed) – safe operation in case of power failure

✓IP54 – robust for installations in damp environments

✓Only 2W operating power — minimal energy consumption

✓Tested for up to 100,000 switching cycles

Paketversand frei ab 100 €

30-Day Returns risk-free

Technical Consulting Mon–Fri · 8 AM–5 PM

Zahlung

The ENGO E30NC-230is a reliable thermoelectric actuatorfor underfloor heating that precisely controlsthe flow of heating water in your underfloor heating system. Thanks to its compact designand energy-efficient control, it is perfect for modern heating systems.

Technische Daten

Type

NC (Normally closed)

Voltage

230 V AC, 50 Hz

Thread

M30×1.5 mm and M28×1.5 mm

Performance

Hub

0.177 in

Protection class

IP54

Lifespan

up to 100,000 switching cycles

Lieferumfang

1 x actuator

Downloads

PDF

Datenblatt & Montageanleitung

↓

★★★★★

Juri Thanel18.09.2025

★★★★★

Verifiziert

"Bin sehr zufrieden, klare Empfehlung. Top Qualität!"

Joseph Dörschner01.07.2025

★★★★★

Verifiziert

"Produkt entspricht der Beschreibung, alles gut."

Alma Mosemann02.05.2025

★★★★★

Verifiziert

"Montage war problemlos, sehr gute Qualität."

Jonas Fischer19.12.2024

★★★★★

Verifiziert

"Funktioniert einwandfrei, einfache Installation."

Claudia Wagner30.11.2024

★★★★★

Verifiziert

"Sehr leiser Antrieb, reagiert schnell."

Patrick Schulz15.11.2024

Shipping

Paketversand 4,99 € · ab 100 € versandkostenfrei

Über 10 kg Versandgewicht 9,99 €

Lieferzeit 3–5 Werktage · Sendungsverfolgung per E-Mail

Warranty

5-year manufacturer's warranty (Engo Controls)

Customer service & technical support

30-day return policy without giving reasons

Quality product from European manufacturing

What does NC (Normally Closed) mean?

NC means: In the de-energized state, the valve is closed. When power is supplied, it opens. In the event of a power failure, the heating remains safely closed – no uncontrolled heating. Alternatively, there are NO (normally open) actuators.

Which manifold models are compatible with the actuator?

The E30NC-230 is designed for M30×1.5mm threads and is compatible with all common heating circuit distributors of this dimension. M28×1.5mm adaptation is also possible.

What is the First-Open feature?

The First-Open function automatically fully opens the actuator when it is switched on for the first time. This facilitates the hydraulic commissioning of the underfloor heating system after installation.

How many actuators do I need?

One actuator is required per heating circuit (zone). A wiring center (e.g., ECB8-230V) controls up to 50 actuators – sufficient for multi-family homes and larger commercial properties.
